Orux 480 Z (Profile)

SKUGL-ORUX480P UPCGL-ORUX480P

Price
$5,713
Orux 480 Z (Profile)

Orux 480 Z (Profile)

$5,713

The Orux 480 Z (Profile) is one of our most advanced lighting fixtures. Part of our Orux series, it is equipped with a 480watt LED while being a versatile fixture capable of achieving a wide zoom range of 4.5º – 55º. Its precision optics feature a light color temperature of 6,500k, CMY + CTO color mixing, and a color wheel that is equipped with 7 colors + open which gives the user a full color spectrum from soothing pastels to rich saturated colors. One of its best features is its framing system which has (8) independently controlled blades which allows the creation of a variety of shapes. Also featured is its 8-facet prism, 1 static gobo wheel + 1 rotational gobo wheel which combines for 16 metal gobos. The Orux 480 Z is the perfect LED moving fixture for any sized venue looking to include advanced programming & looks.

Light Source:

  • LED Power: 480w LED
  • Light Source Color: 6,500K
  • CMY + CTO Color Mixing
  • 20,000 hours LED lifetime
  • CRI: ≥74 or ≥90

Effects:

  • 1 Color Wheel: 7 colors + Open
  • Motorized Zoom 4.5º – 55º
  • CMY Color Mixing
  • CTO Filter: 7,100k-2,500k
  • Framing System: (8) independently controlled blades (90º rotation)
  • 1 Static Gobo Wheel: 8 interchangeable + Open
  • 1 Rotational Gobo Wheel: 8 Interchangeable + Open
  • Prism: 5 facet prism
  • Animation Wheel
  • Linear Focus
  • Frost Filter
  • Strobe: High Speed Strobe Effect 1-20 flashes per second
  • Color Output: Linear Color System

Housing:

  • Internal Housing: Die-casting Aluminum
  • External Housing: High Temperature Strength Plastic
  • Display: 4 Button Menu
  • DMX in & out: 3-Pin & 5- Pin DMX input & output
  • Power: True One PowerCon™ Input

Electrical:

  • Voltage: AC100-240V
  • Max Power: 600w @ 120v

Control:

  • Control Protocol: DMX 512/ 3-pin interfaces
  • Control System: DMX, Auto run, Master/Slave, and Sound
  • DMX Channels: 34 CH, 54 CH

Working Environment:

  • Cooling System: Efficient Low Fan Cooling System/ Intelligent fan speed function (Quiet Mode)
  • IP Grade: IP-20

Dimensions:

  • Net Weight: 75 lbs
  • Dimensions: 33x15x18″ in
