High End Systems Ministar 300 W , 9,700 lumens, 6.5°–48° zoom Moving Head

SKU MS-UB-MI
Barcode 2540A1100-B
Sale price
$3,900
Regular price
$4,875
You save
20%
High End Systems Ministar 300 W , 9,700 lumens, 6.5°–48° zoom Moving Head

High End Systems Ministar 300 W , 9,700 lumens, 6.5°–48° zoom Moving Head

$3,900
$4,875

The High End Systems Ministar is a dynamic and powerful LED moving‑head fixture engineered for creative lighting applications in theatres, clubs, stages, broadcast studios, and event productions. With a 300 W LED engine delivering up to 9,700 lumens, it offers strong output and vibrant performance while maintaining a compact footprint. Its motorized 6.5°–48° zoom gives lighting designers flexible beam shaping from tight beams to wide washes. Featuring advanced colour and effects systems, versatile gobos, and multiple control options, the Ministar combines punchy brightness with creative versatility — making it ideal for both feature lighting and atmospheric effects in professional rigs.

Features

  • 300 W high‑output LED engine for a bright performance intensity.

  • 9,700 lumens total output, suitable for medium to large venues.

  • Motorized 6.5°–48° zoom for flexible beam shaping and wash control.

  • Dual gobo wheels with rotating and fixed patterns for creative effects.

  • Colour mixing and effects wheel for rich visual dynamics.

  • Variable diffusion and prism options (where applicable) for enhanced beam textures.

  • DMX‑512 control with multiple channel modes.

  • Compact, road‑ready design ideal for touring and rental applications.

Specifications

Light Source & Brightness

  • LED Engine: 300 W white LED source.

  • Maximum Output: ~9,700 lumens.

  • LED Lifespan: Typically ~50,000 hours.

Optical

  • Zoom Range: Motorized 6.5°–48°.

  • Gobo Projection: Dual rotating and fixed gobo wheels.

  • Diffusion and Prism Effects for creative beam shaping.

Control & Connectivity

  • Control Protocol: DMX‑512.

  • DMX Connectors: 5‑pin XLR.

  • User Interface: Local display with navigation buttons.

Electrical

  • Input Voltage: 100–240 V AC, 50/60 Hz.

  • Power Input: powerCON TRUE1 connections (in and thru).

  • Typical Power Consumption: ~450 W.

Physical

  • Mounting: Yoke included for flexible orientation.

  • Weight: Approx. ~16–18 kg (unit only).

  • IP Rating: Indoor use (IP20).

Applications

  • Nightclubs, theatres, stages

  • Event lighting and corporate shows

  • Production rigs and broadcast environments

  • Rental and touring systems
