Festoon 2 RGB
Festoon 2 RGB
SKU:CHVT-FESTOON2RGB UPC:CHVT-FESTOON2RGB
Specifications
DMX Channels: 3, 9, Pixel or Pixel+DMX Connectors: 3-pin XLRLight Source: 5 SMD LEDs (tri-color RGB) 0.1 W, (20 mA), 50,000 hours life expectancy (per bulb)Strobe Rate: 0 to 10 HzPWM Frequency: 604 HzCoverage Angle: 360°IP Rating: IP54Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)Power and Current: (20 Bulbs): 42 W, 0.3 A @ 120 V, 60 Hz
(40 Bulbs): 77 W, 0.7A @ 120 V, 60 Hz
(60 Bulbs): 107 W, 0.9A @ 120 V, 60 Hz
(20 Bulbs): 47 W, 0.2 A @ 230 V, 50 Hz
(40 Bulbs): 78 W, 0.3 A @ 230 V, 50 Hz
(60 Bulbs): 108 W, 0.5 A @ 230 V, 50 HzWeight: (Controller): 3.6 lbs (1.4 kg)Size: (String): 590.5 x 2.4 x 5.2 in (15,000 x 60 x 133 mm)
(Controller): 7.25 x 8 x 2 in (184 x 203 x 49 mm)Approvals: CEOptional Controllers: IRC-6
WHAT'S INCLUDED
Controller20 RGB bulbsExtension cable (5 m)Power cordQuick Reference Guide
