ETC CSLINEAR4DB-5 ColorSource Linear 4 Deep Blue, XLR, silver

The ETC ColorSource Linear 4 Deep Blue LED wash fixture in silver is a sleek, high‑quality strip light designed to deliver consistent, vibrant illumination for theatrical cycloramas, walls, stages, and architectural elements. Featuring ETC’s Deep Blue RGB‑L LED array, the fixture replaces standard blue with indigo for richer blues and magentas, creating expressive colour washes that standard fixtures can’t match. Its homogenized optics provide a smooth, even beam with no visible pixelation — and the robust aluminum housing ensures dependable performance in demanding professional environments. With a simple seven‑segment interface, onboard presets/sequences, and both DMX via 5‑pin XLR or RJ45 control, it integrates easily into any lighting rig while supporting multiple units mounted end‑to‑end for seamless light coverage.

Features

• Deep Blue RGB‑L LED array (red, green, deep blue/indigo, lime) for richer blues and magentas than standard RGB arrays.

• Homogenized optics deliver a smooth, even wash with minimal pixelation.

• Simple 7‑segment, 3‑button interface for quick local configuration.

• powerCON® in and thru power connections for easy daisy‑chaining.

• DMX in and thru (5‑pin XLR or RJ45) with RDM support for flexible control options.

• Onboard presets (12) and sequences (5) for standalone operation.

• LED droop compensation and optical calibration for consistent output and colour across fixtures.

• Durable, tour‑ready aluminum housing in silver finish.

Specifications

Light Source & Output

• LEDs: 40 Lumileds LUXEON® Z LED emitters (Deep Blue RGB‑L array).

• Colour mix: Red, Green, Deep Blue (Indigo), Lime.

• LED life: ~20,000 hours at 70 % intensity (typical estimate).

Optics

• Homogenized optics for even wash light.

• Primary field angle approx. 24.9°, beam angle ~14.5°.

• Secondary lenses/filters optional (sold separately).

Control & Connectivity

• Control protocols: DMX512 with RDM support.

• Connectors: 5‑pin XLR + RJ45 (optional).

• Local interface: Seven‑segment display with 3‑button control.

• Onboard modes: RGB, IRGBS, Direct, single channel.

• Virtual dimming: 15‑bit engine for smooth theatrical fades.

Electrical

• Voltage: 100‑240 VAC, 50/60 Hz universal.

• Power connections: powerCON in/thru.

• Inrush: ~35 A (120 V) / ~49 A (240 V) first half‑cycle.

Physical

• Housing: Tour‑ready aluminum, silver finish.

• Length: ~2 m (78.4 in) – four cell units allow continuous end‑to‑end mounting.

• Mounting: Trunnions included for flexible hanging or floor placement.

• IP rating: IP20 (indoor use).

Control & Standalone

• Onboard presets: 12.

• Onboard sequences: 5.
